1
Engine displacement
450
2
Year
2023
3
Trim
rx-450f-replica
4
Parts Catalog
OIL PUMP
5
Parts Diagram
Parts Catalog
CYLINDER HEAD
by
IGNITION SYSTEM
OIL PUMP
64
40
40
40
40
8
24
14
13
12
35
50
50
50
50
50
50
29
29
32
32
22
37
37
30
20
20
31
41
16
5
36
34
57
57
19
6
18
18
21
23
23
58
58
58
15
62
49
53
55
54
59
60
61
63
51
51
51
51
51
51
51
39
38
1
10
27
28
7
33
11
9
17
4
25
56
1
Oil radiator
76738051000
Not Available
4
Cylinder pin
79438006000M01
Not Available
5
TAB WASHER DIN6799-RS 6,0
0799060000
$3,89 Unit Price incl. VAT
6
STOP DISK 8,1 X 15 X 0,5
58038007755
$3,89 Unit Price incl. VAT
7
oil pump gear
79438001019M03
Not Available
8
HH collar screw M6x16 TX30 SL
0025060166S
$3,89 Unit Price incl. VAT
9
oil pump cover
79438003000M02
Not Available
10
OILPUMP ROTOR 15MM G-164
77038011000
$66,91 Unit Price incl. VAT
11
Oil pump shaft
79438002000M02
Not Available
12
NEEDLEROL.DIN5402 NRA 2,5X19,8
0402251980
$2,59 Unit Price incl. VAT
13
NEEDLE ROLLER DIN5402 2,5X11,8
0402251180
$2,59 Unit Price incl. VAT
14
needle roller NRB 4x15.8 G2
0402041580
$3,89 Unit Price incl. VAT
15
ROTOR SET 22MM
61238011100
$26,72 Unit Price incl. VAT
16
O-RING 44,00X2,00 VITON
0770440020
$5,19 Unit Price incl. VAT
17
OIL PUMP COVER
79438004100
$102,80 Unit Price incl. VAT
18
CU-SEAL RING DIN7603-12X18X1,5
58038022000
$3,89 Unit Price incl. VAT
19
OILDRAIN PLUG W.MAG. M 12X1,5
58030021000
$16,22 Unit Price incl. VAT
20
O-RING 12,5X1,5 VITON V75
07701250151
$6,49 Unit Price incl. VAT
21
OIL SCREEN
59038016100
$18,27 Unit Price incl. VAT
22
O-RING 17,17X1,78 GLO
0770020170
$3,89 Unit Price incl. VAT
23
PLUG M20X1,5 WS=13
59038017100
$12,00 Unit Price incl. VAT
24
BALL DIN5401-9
0401090003
$3,89 Unit Price incl. VAT
25
Compression Spring
79438026000M01
$3,56 Unit Price incl. VAT
27
Locking screw oil system
78036024000M01
Not Available
28
OIL SCREEN CPL.
78138015001
$53,47 Unit Price incl. VAT
29
O-RING 12X2 VITON GREEN
0770012021
$3,89 Unit Price incl. VAT
30
O-RING 12,5X1,5 NBR
0770125015
$3,89 Unit Price incl. VAT
31
O-RING 17,00X2,00
0770170200
$3,89 Unit Price incl. VAT
32
O-RING 17X2,5
0770017025
Not Available
33
Intermediate gear 33 Z
79438001033M04
Not Available
34
THRUST WASH. DIN0988-16X22X0,5
0988162205
$3,89 Unit Price incl. VAT
35
CIRCLIP DIN0471-15X1
0471150010
$3,89 Unit Price incl. VAT
36
CYL. SCREW DIN6912 M5X14 8.8
0984050143S
$3,89 Unit Price incl. VAT
37
O-RING 39,34X2,62
07700390261
$3,89 Unit Price incl. VAT
38
Oil adapter
76738050000
Not Available
39
Tube f/ oil adapte
76738035000
Not Available
40
HH collar screw M5x16 TX30
0025050166
$3,89 Unit Price incl. VAT
41
O-RING 33,05X1,78
07703305178
$5,19 Unit Price incl. VAT
49
OIL JET
76438034000
Not Available
50
sealing ring DIN 7603 10x14x1
0603100141
$3,89 Unit Price incl. VAT
51
Hollow screw M10x1 wrench size
76738030000
Not Available
53
COVER OIL FILTER 1
76438041000
Not Available
54
HOUSING OI FILTER
76438043000
Not Available
55
COVER OIL FILTER 2
76438042000
Not Available
56
OIL FILTER
83538005000
$18,01 Unit Price incl. VAT
57
RUBBER SLEEVE D=12MM
41001052000
$6,49 Unit Price incl. VAT
58
SPECIAL SCREW M6X21 WS=8
60035001000
$5,19 Unit Price incl. VAT
59
OIL PIPE L=105MM
76438053000
Not Available
60
OIL PIPE L=615MM
76438054000
Not Available
61
OIL PIPE L=696MM
76438055000
Not Available
62
CABLE TIE 200MM
76311093200
$2,59 Unit Price incl. VAT
63
Plug-in base
76711094010
Not Available
64
WASHER DIN9021-A 6,4
0021060003
$3,89 Unit Price incl. VAT
The diagrams are provided for reference only. If in doubt, our specialists are available to answer your questions. When adding a part to your cart, please make sure to select the desired quantity. The unit price shown is the price for one unit of each part number.
