CARBURETOR
1
CARBURADOR EC 250 4T 2011 YAMAHA
BFS780012511
Not Available
2
GASKET EC 250 4T 2010
5JG1495900
Not Available
3
BOLT EC250 4T 2010
9131604012
Not Available
4
SCREW EC 250 4T 2010
6881459200
Not Available
5
WASHER, PLATE EC 250 4T 2010
9020208045
Not Available
6
WASHER EC 250 4T 2010
5JG1495100
Not Available
7
SCREW ADJUST EC 250 4T 2010
5JG1452200
Not Available
8
BOISSEAU FCR
2S21438800
Not Available
9
ROULETTE BOIS. FCR
3TJ1426740
Not Available
10
PLAQUE BOISSEAU FCR 250/450
5JG1454601
Not Available
11
JOINT PLAQ. BOIS. FCR
4FN1499700
Not Available
12
NEEDLE (NNGU)
5UM14916LU
Not Available
13
CLIP EC 250 4T 2010
3TJ1415940
Not Available
14
SCREWW, ADJUST EC 250 4T 2010
5JG1452100
Not Available
15
SPRING EC 250 4T 2010
5JG1427500
Not Available
16
COLLAR EC 250 4T 2010
5JG1426400
Not Available
17
JET, NEEDLE
5TJ1494700
Not Available
18
JET, MAIN (160) EC 250 4T 2010
4MX1494339
Not Available
19
JET (#115)
5UM1494F30
Not Available
20
JET, SLOW (45) EC 250 4T 2010
4MX1494805
Not Available
21
JET (68) EC 250 4T 2010
3TJ1494F14
Not Available
22
JET, MAIN (70) EC 250 4T 2010
5TA1494315
Not Available
23
JET (70) EC 250 4T 2010
4JT1494F15
Not Available
24
KIT VIS. RICH. FCR
5NL1410500
Not Available
25
FLOAT EC 250 4T 2010
4SR1498500
Not Available
26
PIN, FLOAT ARM EC 250 4T 2010
6761454800
Not Available
27
PONTEAU FCR ECF 250/450
4MX1439200
Not Available
28
CLIP EC 250 4T 2010
6331415900
Not Available
29
JOINT CUVE FCR
5JG1498400
Not Available
30
PLUG, DRAIN EC 250 4T 2010
3TJ1419140
Not Available
31
COVER 1 EC 250 4T 2010
3TJ1429340
Not Available
32
DIAPHRAGM ASSY EC 250 4T 2010
5JG1494076
Not Available
33
GASKET EC 250 4T 2010
3TJ1453640
Not Available
34
RESSORT DIPHRAGM EC 250 4T 2010
3TJ1493340
Not Available
35
O-RING EC 250 4T 2010
6H41456100
Not Available
36
PLUNGER, STARTER
5XC1417100
Not Available
37
PLUNGER, STARTER EC 250 4T 2010
5TA1437100
Not Available
38
SPRING, PLUNGER EC 250 4T 2010
5TA1433500
Not Available
39
SCREW EC 250 4T 2010
5TA1499100
Not Available
40
CAP PLUNGER
2S21437400
Not Available
41
GUIDE, CABLE EC 250 4T 2010
5TA1415500
Not Available
42
SEAL EC 250 4T 2010
5TA1499700
Not Available
43
ROD. STARTER EC 250 4T 2010
5JG1437900
Not Available
44
O-RING
3TJ1456440
Not Available
45
SCREW, THROTTLE
5XC1492200
Not Available
46
WASHER, PLATE EC 250 4T 2010
9020108410
Not Available
47
SPRING, THROTTLE STOP EC 250 4T
5TA1493400
Not Available
48
TPS FCR EC250
5XC8588500
Not Available
49
O-RING EC 250 4T 2010
5NX1456200
Not Available
50
SCREW EC 250 4T 2010
5NX1421600
Not Available
51
O-RING EC 250 4T 2010
4MX1456100
Not Available
52
BOUCHON DE CUVE ECF 250/450
4MX1411500
Not Available
53
CLIP EC 250 4T 2010
3TJ1413740
Not Available
54
PLATE EC 250 4T 2010
5BE1414600
Not Available
55
HOLDER EC 250 4T 2010
5TA1426100
Not Available
56
PIPE EC 250 4T 2010
5UL1419600
Not Available
57
PIPE EC 250 4T 2010
5TA1419700
Not Available
58
HOSE, EC 250 4T 2010
5TJ1498700
Not Available
59
PLATE EC 250 4T 2010
5JG1434600
Not Available
60
SCREW EC 250 4T 2010
5JG1456500
Not Available
61
SPRING, ADJUST SCREW EC 250 4T 2
5JG1453100
Not Available
62
SCREW
5UM1459100
Not Available
63
PLATE, EC 250 4T 2010
5PA1414600
Not Available
64
DIAPHRAGM ASSY EC 250 4T 2010
5GS1494000
Not Available
65
COUVERCLE ENRICHIS. FCR 4T
5GS1495800
Not Available
66
SPRING, DIAPHRAGM EC 250 4T 2010
5GS1493300
Not Available
68
PLATE
5TJ1424300
Not Available
69
SREW, PAN HEAD
9850204010
Not Available
70
WASHER, SPRING
9290204100
Not Available
71
PIPE
5UM1419700
Not Available
72
PIPE AD ECF 250/300 10-14
5XC1359730
Not Available
73
VIS DE SERRAGE M6X25 ECF 2015
9131206025
Not Available
74
COLLIER DURITE
9045057010
Not Available
75
EXTENSI�N SCREW
BFS780954513
Not Available
The diagrams are provided for reference only. If in doubt, our specialists are available to answer your questions. When adding a part to your cart, please make sure to select the desired quantity. The unit price shown is the price for one unit of each part number.

List of machines using this diagram

RACING 300 2014
